Item #1302 A Powerful Röntgen Ray Tube with a Pure Electron Discharge. WILLIAM COOLIDGE.
A Powerful Röntgen Ray Tube with a Pure Electron Discharge

A Powerful Röntgen Ray Tube with a Pure Electron Discharge

FIRST PRINTING IN ORIGINAL WRAPPERS announcing the invention of the Coolidge tube, the basis for all modern X-ray tubes; "the single most important event in the progress of radiology."

“While many clever designs were implemented to compensate for the technical limitations of early X-ray tubes, the true milestone--what some experts call ‘the single most important event in the progress of radiology’--did not occur until nearly 20 years later [after Röntgen’s discovery of the X-ray]. In 1913, William Coolidge, working in the General Electric Research Laboratory, developed the first so-called ‘hot’ X-ray tube, subsequently called the Coolidge tube. Based on his earlier research, Coolidge had figured out how to make the cathode out of the metal tungsten, which has the highest melting point of all metals. With a cathode made primarily of tungsten, cathode rays could be generated by running an electric current through the cathode and heating it; the more the cathode was heated, the more cathode rays it emitted. Thus, with cathode rays generated by heat rather than gas molecule collisions, the Coolidge tube could operate in a perfect vacuum.

“Thanks to these and other design changes, the Coolidge tube was not only more stable--producing consistent, reliable exposures--but operators could also now independently control X-ray intensity and penetration. X-ray intensity was controlled by changing the temperature of the cathode, while penetration was controlled by changing the tube voltage. Finally, by operating in a true vacuum, Coolidge tubes were less finicky and could function almost indefinitely, unless broken or badly abused.

“By the mid-1920s, the Coolidge tube had essentially replaced the old gas-filled tubes. In addition, Coolidge later designed other innovations so that higher voltages could be used to produce higher frequency X-rays. This led to the development of so-called ‘deep therapy,’ in which X-rays are used to treat deeper tissues without excessively damaging outer layers of skin. Thanks to Coolidge’s milestone redesign of the X-ray tube, the use of X-rays in medicine--for both diagnostic and therapeutic applications--expanded widely throughout the world from the 1920s ad onward. Today, Coolidge’s ‘hot’ tube design is still the basis for all modern X-ray tubes” (Jon Queijo, Breakthrough! How the 10 Greatest Discoveries in Medicine Saved Millions and Changed Our View of the World).

IN: The Physical Review, Vol II, Second Series, No. 6, pp. 409-430. Lancaster, PA and Ithaca, NY: The American Physical Society, December 1913. Octavo, original wrapper; custom box. Some toning and light chipping to wrappers, rear wrapper detached along neat split. RARE in original wrappers.

Price: $3,300 .
